The HS Grup ST60 covers primary currents from 400 to 1250 A. Its Ø45 mm aperture also accommodates busbars up to 60 × 10 mm or 50 × 30 mm. The series offers several secondary output, accuracy class, and burden options for larger electrical panels.
| Technical detail | Listed options |
|---|---|
| Primary current | 400–1250 A |
| Secondary output | 5 A; 1 A; 333 mV; 100 mV; 150 mV |
| Accuracy class | 0.25; 0.5S; 0.2; 0.5; 1 |
| Burden for current-output versions | 1–5 VA; 2.5–10 VA; 5–15 VA; 10–20 VA; 15–30 VA |
| Cable aperture | Ø45 mm |
| Busbar sizes | 60 × 10 mm; 50 × 30 mm |
| Maximum system voltage shown | 0.72 / 3 kV |
